ICO300-83B

Robust DIN-rail Fanless Embedded System with Intel® Celeron® Processor N3350, Isolated COM, LAN and DIO

  • Features
  • Specifications
  • Ordering Information
  • Download
  • Related Products
    • Intel® Celeron® processor N3350 (1.1 GHz)
    • Fanless design
    • Wide operating temperature range from -20°C to +70°C (-40°C to +70°C for option)
    • 2 or 4 isolated COM ports (optional)
    • 2 full-size PCI Express Mini Card slots
    • 1 mSATA and 2.5" SATA drive
    • 12 ~ 24 VDC wide range power input
  • CPU
    • Intel® Celeron® N3350 processor (1.1 GHz, Dual Core)
    Chipset
    • SoC integrated
    System Memory
    • 1 x SO-DIMM DDR3L-1866, up to 8GB
    COM
    • 4 x isolated RS-232/422/485 or 2 x isolated RS-232/422/485
    • 4 x RS-232/422/485
    USB
    • 4 x USB 3.0
    Ethernet
    • 2 x 10/100/1000 Mbps
    • Intel® i211AT for ICO300-83B
      Intel® i210IT for ICO300-83B-WT
    PoE
    • N/A
    CANbus
    • N/A
    Digital I/O
    • 1 x DI/DO (8-bit programmable, DB9 female connector)
    Display
    • 1 x VGA or 1 x HDMI (optional)
    Wireless
    • 2 x Full-size PCI Express Mini Card slot
    Storage
    • 1 x mSATA
    • 1 x 2.5" 9.5 mm SATA drive
    Others
    • 1 x DC power input with terminal block
    Power Supply
    • Power Input Rating: 12 - 24 VDC
    • Power Protection: DC Version, OVP, Reverse protection
    Watchdog Timer
    • 255 levels, 1 ~ 255 sec./min.
    Construction
    • Extruded aluminum and heavy-duty steel, IP40
    Operating Temperature
    • -20°C ~ +70°C (-4°F ~ +158°F)
    • Optional: -40°C ~ +70°C (-40°F ~ +158°F)
    Relative Humidity
    • 10% ~ 95%
    Vibration
    • 2G@5 ~ 500Hz, amplitude 0.35 mm (operation/storage/transport)
    Dimensions
    (W x D x H)
    • 48 x 110 x 155 mm (1.88" x 4.33" x 6.1")
    Weight (net/gross)
    • 1.0 kg (2.2 lb)/1.50 kg (3.3 lb)
    Certificate
    • CE, FCC
    EOS
    • Linux support package
    • Windows® 10
    Mounting
    • DIN rail
    • Wall Mounting
    • ICO300-83B-N3350-4COM-DC
      Robust DIN-rail Fanless Embedded System with Intel® Intel® Celeron® processor N3350 1.1 GHz , 4 COM, 2 GbE LANs, 4 USB, VGA
    • ICO300-83B-N3350-4COM-WT-DC
      Robust DIN-rail Fanless Embedded System with Intel® Intel® Celeron® processor N3350 1.1 GHz , 4 COM, 2 GbE LANs, 4 USB, VGA (-40°C ~ +70°C)
    • ICO300-83B-N3350-2ICOM-DC
      Robust DIN-rail Fanless Embedded System with Intel® Intel® Celeron® processor N33501.1 GHz, 2 isolated COM, 2 GbE LANs, 4 USB, VGA
    • ICO300-83B-N3350-4ICOM-DC
      Robust DIN-rail Fanless Embedded System with Intel® Intel® Celeron® processor N33501.1 GHz , 4 isolated COM, 2 GbE LANs, 4 USB, VGA
    • ICO300-83B-N3350-4ICOM-WT-DC
      Robust DIN-rail Fanless Embedded System with Intel® Intel® Celeron® processor N33501.1 GHz , 4 isolated COM, 2 GbE LANs, 4 USB, VGA (-40°C ~ +70°C)
    • mSATA
      4GB and above
    • 2.5" SATA drive
    • DDR3L SO-DIMM
      2GB ~ 8GB (with W.T. memory)
    • Wall mount kit
    • Mini PCIe module
      Wi-Fi/Bluetooth/3G/4G/GPS
