PICO821

Intel® Atom™ Z510/ Z530 Pico-ITX SBC with LVDS, PATA, LAN and CF

  • Features
  • Ordering Information
  • Download
  • Related Products
    • Ultra low power Intel® Atom™ processor Z510/ Z530
    • 1 COM and 5 USB 2.0 (1 client port) supported
    • LVDS LCD supported
    • 1 PATA and 1 CompactFlash™
    • One 10/100/1000Mbps Ethernet
    • Minimum 9 Watt power requirement

    Introduction

    Axiomtek's PICO821 Pico-ITX SBC supports ultra low power Intel® Atom™ processors Z510 1.1GHz and Z530 1.6GHz at 400/533 FSB with the Intel® System Controller Hub US15W. The PICO821 is an incredibly small 10 x 7.2 cm embedded board based on Pico-ITX form factor, the world's smallest x86 embedded board. Instead of built-up a full set of I/O connectors soldered onto the board edge, the PICO821 provides internal connectors for COM, Gigabit Ethernet, USB, audio, video and more, which provides embedded developers with flexibility. This extreme small form factor embedded platform can meet today's customers' need of fanless operation, low-power consumption, compact-size, flexibility and versatile I/O. Its applications include in-vehicle PCs, in-flight entertainment systems or industrial automation systems, and even ultra portable devices.

    • PICO821LGA-Z510 (P/N-E38H821100)
      Pico-ITX SBC with Intel® Atom™ processor Z510 1.1 GHz, LVDS, PATA, 10/100/1000Mbps Ethernet, CF and DVI-D kit
    • PICO821LGA-Z530 (P/N-E38H821102)
      Pico-ITX SBC with Intel® Atom™ processor Z530 1.6 GHz, LVDS, PATA, 10/100/1000Mbps Ethernet, CF and DVI-D kit
  • BIOS

    Date Description Version File Size
    2010/1/8 Standard BIOS V1.01 539.1KB

    Drivers

    Date Description Version File Size
    2012/11/9 Audio Driver For Win7 Driver CD A1.2 54,817.7KB
    2012/11/9 Ethernet Driver For Win7 Driver CD A1.2 5,792.8KB
    2012/11/9 VGA Driver For Win7 Driver CD A1.2 28,554.9KB
    2011/9/28 uAPI for Windows A1.0 32,945.7KB
    2010/1/8 Chipset Driver (Supported Win XP & 7) Driver CD A1.2 8,095.2KB
    2010/1/8 VGA Driver Driver CD A1.0 66,290.9KB
    2010/1/8 HD Audio Driver Driver CD A1.0 30,258.2KB
    2010/1/8 Ethernet Driver Driver CD A1.0 5,941.5KB
    2010/1/8 USB Client Driver CD A1.2 38,105.0KB

    Manual

    Date Description Version File Size
    2010/2/8 User's Manual A3 1,885.1KB
    2010/1/8 Quick Manual A1 132.7KB

    Software

    The object is under update temporarily, please download it later.

    CE Conformity Declaration

    Date Description Version File Size
    2012/4/16 PICO821 CE-Conformity Declaration N/A 63.6KB

    Technical Announcement

    The object is under update temporarily, please download it later.

    Mechanical

    Date Description Version File Size
    2012/2/14 PICO821DM20120209 N/A 113.6KB
