Features
- Cost-effective with fanless and cableless design
- Intel® Celeron® processor N3350/Pentium® processor N4200, reliable F1 stepping version CPU
- 4 isolated COM, 4 USB, 2 GbE LAN
- 8-bit programmable DIO for IoT gateway applications
- Wide operating temperature range from -40°C to +70°C
- 12 to 24 VDC wide range power input
- OVP, UVP, OCP, RPP power protection design
- eAPI intelligent remote monitoring software for IIoT
Introduction
The GOT3177T-834 is a 17-inch SXGA, fanless panel PC powered by Intel® Bay Trail-D Celeron® processor. This all-in-one industrial-touch panel PC is equipped with a 5:4 aspect ratio flush, resistive touch LCD display with 350nits. The panel system offers a slim design and flexible architecture for fast system deployment and supports noiseless operation. Its wide operating temperature range (-10°C to +50°C) offers great reliability for operations in harsh environments. Its waterproof enclosure (IP65 front bezel) protects the system from liquid damage. The GOT3177T-834 is an excellent human machine interface platform for applications in automation, transportation, oil pipe monitoring systems, self-service kiosk, and environmental monitoring.
