| Form Factor |
|
| CPU |
- 14th/13th/12th gen Core™ i9/i7/i5/i3, Pentium® or Celeron® processor (Codenamed Alder Lake S/Raptor Lake S/Raptor Lake Refresh)
|
| Chipset |
|
| System Memory |
- 4 x DDR5-4400 MHz ECC/non-ECC UDIMM, up to 256 GB
|
| BIOS |
|
| Ethernet |
- 8 x GbE RJ-45
- 2 x SFP
- 2 x NIC module through MIO153 I/O board (optional)
|
| LAN Bypass |
|
| LAN Module |
- 2 x NIC module through MIO153 I/O board (optional)
|
| Storage |
- 2 x 2.5" SATA HDD/SSD bays
|
| Expansion |
- 1 x M.2 Key M slot for AI card (via I/O board MIO153)
- 1 x M.2 Key B 3052 slot with SIM card for 5G (PCIe x2 by default, USB 3.1 optional)
- 1 x PCIe Mini Card slot with SIM card (PCIe x1 and USB 2.0 by default, co-lay with SATA 3.0)
- 1 x PCIe x8 slot (optional; via I/O board MIO153 and riser card EIO150)
|
| I/O Interface |
- 1 x HDMI
- 1 x LCM (16x2 character)
- 6 LEDs for power, storage, GPIO, and LAN bypass
- 1 x console (RJ-45/Type C)
- 2 x USB 3.0
|
| Power Supply |
- 400W single power supply
- 400W 1U redundant power supply
|
| LCM Module |
|
| Watchdog Timer |
- 255 stepping for system reset
- 8 stepping for LAN Bypass
|
| Operating Temperature |
- 0°C to +45°C (+32°F to +113°F)
|
Dimensions
(H x W x D) |
- 44 x 430 x 450 mm (1.73" x 16.93" x 17.7")
|
| Weight (net/gross) |
- 6 kg/9.5 kg (single power)
- 7.3 kg/10.8 kg (redundant power)
|
| OS |
|
| Certifications |
|
| Others |
- Onboard TPM 2.0
- BMC AST2600, IPMI 2.0 (by project)
|
