CPU |
- 7th gen Intel® Core™ i7/i5/i3 and Celeron® processor onboard
|
Chipset |
|
System Memory |
- 1 x 260-pin DDR4-2133 SO-DIMM, up to 16GB
|
BIOS |
|
COM |
|
USB |
|
Ethernet |
- 2 x 10/100/1000 Mbps Ethernet (Intel® I219-LM & Intel® I210-AT)
|
Display |
- 1 x DisplayPort++
- 1 x LVDS
|
Digital I/O |
- 4-channel in/out programmable
|
Audio |
|
Storage |
- 1 x M.2 Key B 2242 (SATA, USB 2.0, optional PCIe x2)
|
Expansion |
- 1 x M.2 Key E 2230 (PCIe x1, USB 2.0)
|
Others |
- SMBus; compatible with I2C
- Intel® AMT 11
|
Battery |
|
Power Input |
- 2 x 2-pin connector
- +12 VDC-in only
- AT Auto Power On function supported
|
Power Requirements |
- Intel® Core™ i7-7600U @2.8 GHz 8GB DDR4 max. RMS. +12V@3.2A
- Intel® Core™ i5-7300U @2.6 GHz 8GB DDR4 max. RMS. +12V@2.6A
- Intel® Core™ i3-7100U @2.4 GHz 8GB DDR4 max. RMS. +12V@2.3A
- Intel® Celeron® 3965U @2.2 GHz 8GB DDR4 max. RMS. +12V@1.6A
|
Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
Hardware Monitoring |
|
Operating Temperature |
- -20°C to +60°C (-4°F to 140°F)
|
Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
Dimensions |
|
Board Thickness |
|
Certifications |
|
Industrial Chassis |
|
