CPU |
- Dual LGA3647 server-grade Intel® Xeon® Gold 6226R
- processors 2.9GHz, 22MB Cache 16 cores
|
Chipset |
- PCH: Intel® C621, TDP 15W
- BMC: ASpeed AST2500A2-GP
- Embedded Graphics SoC: SiliconMotion SM768
|
System Memory |
- 12 x DDR4-2933 ECC RDIMM, up to 384GB
|
Graphics |
- Single HDMI 1.4 supported by SM768
|
BIOS |
|
Remote Management |
|
COM |
|
USB |
|
Ethernet |
- 1 x LAN (BMC/IPMI)
- 1 x Network card supports dual 10G Base-T & dual SFP+
|
Display |
|
Storage |
- 2 x 2.5" hot-swappable SATA SSD slot, in upport of 2 x 256G SSD (RAID 1)
- 2 x 2.5" hot-swappable U.2 SSD slot in support of 1 x 6.4T U.2 SSD (RAID 0)
|
Expansion |
- 2 PCIe riser cards inside:
- 2 x PCIe x16 Gen 3.0 slots
- 1 x PCIe x16 slot, 1x PCIe x8 slot, M.2 22110-M slot
|
Others |
- 2 x 110 to 240 VAC power input
- 2 x LED status (power-on, SSD act.)
|
Power Supply |
- 2 x 1200W redundant ATX power supply
|
Watchdog Timer |
- Reset: 1 - 65535 sec./min. and 1 sec. or 1 min./step
|
Operating Temperature |
- 0°C to +40°C (32°F to +104°F)
|
Relative Humidity |
- 10% - 95%, non-condensing
|
Vibration Endurance |
|
Dimensions (W x D x H) |
- 430 x 600 x 88 mm (19” x 19.4” x 3.5”)
|
Weight (net/gross) |
- 11.9 kg (26 lb) /16.10 kg (35 lb)
|
EOS Support |
- CentOS 7.6 & Windows 10 IoT
|
Certifications |
- CE, IEC 62368-1, FCC Class A compliant
|
