Features
- 15.6" TFT LCD with wide viewing angle; 300 nits of brightness
- Supports Intel® Smart Display Module Large (Intel® SDM-L)
- with Intel® Core™ i5/i3 and Intel® Celeron® processor (Whiskey Lake)
- Super slim design with only 8.7 cm thickness
- Supports Verifone & Ingenico EFT terminal
- Dual illuminating status LEDs
- All-in-one seamless modular design
Introduction
The SDM500L is powered by the onboard 8th generation Intel® Core™ i7/i5/i3 processor with the Intel® Generation 9 HD Graphics chipset. The Intel® Smart Display Module-Large (Intel® SDM-L) measures just 175 x 100 mm and a maximum z-height of 1.6 mm, which is well-suited for ultra-slim displays. It can be easily connected to an SDM-compliant display via a high-speed PCIe x8 edge connector - which supports 4K resolution displays and video capture and has built-in USB 3.0, HDMI 2.0, DisplayPort 1.2, Serial TX/RX and I2C signals. With its excellent graphics performance and installation flexibility, the incredible signage module can satisfy diverse industry requirements and support a wide range of digital signage applications such as bedside terminals for hospital patients or factory automation solutions.
