CPU |
- Intel® Core™ i7-1265UE (1.7GHz/10C/15W)
- Intel® Core™ i5-1245UE (1.5GHz/10C/15W)
- Intel® Core™ i3-1215UE (1.2GHz/6C/15W)
- Intel® Celeron® 7305E (1GHz/5C/15W)
|
Chipset |
|
System Memory |
- 1 x DDR4-3200 SO-DIMM, up to 32GB
|
COM |
- 4 x Isolated RS-232/422/485 (4-wire, Phoenix-type connectors, only for full type)
- Isolation voltage: 2 kV
|
USB |
|
Ethernet |
- 4 x RJ-45 isolated 2.5 GbE LAN (Intel® I226-IT )
- Isolation voltage: 1.5 kV
|
PoE |
|
CANbus |
|
Digital I/O |
- 1 x Isolated 8-in/8-out DIO (only for full type)
- Isolation voltage: 2 kV
|
Analog Input |
|
Display |
|
Expansion |
- 1 x M.2 Key B 3050/3052 slot: PCIe/USB (for 5G/Wi-Fi)
- 1 x Full-size Rev.1.2 PCI Express Mini Card slot: PCIe/USB (for LTE/Wi-Fi)
- 1 x Full-size Rev.1.2 PCI Express Mini Card slot: SATA/USB (for mSATA/Wi-Fi)
- 3 x SIM slot (1 for M.2 and 2 for full-size PCI Express Mini Card)
|
Storage |
- 1 x Internal 2.5” SATA Drive
- 1 x mSATA (occupied 1 x PCI Express Mini Card slot)
- 1 x M.2 (PCIe Gen2 x4): NVMe (2242/2280) (fully type only)
|
Others |
- TPM 2.0
- 5 x Antenna opening
|
Power |
- 1 x Terminal block, 9 to 36 VDC, typical 2/24V
- Power consumption: full loading
- - 54.82W (with 12VDC)
- - 56.52W (with 24VDC)
- MTBF: 47,832 (hrs, @50°C)
|
Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
Construction |
- Extruded aluminum and heavy-duty steel, IP30
|
Operating Temperature |
- Cold boot at -40°C
- With fan kit: -40°C to +70°C (-40°F to +158°F)
- Without fan kit:
- With i7-1265UE or i5-1245UE: -40°C to +50°C (-40°F to +122°F)
- With i3-1215UE or 7305E: -40°C to +60°C (-40°F to +140°F)
|
Relative Humidity |
|
Vibration |
- 2 Gms with storage (5 to 500Hz, X/Y/Z direction; random, operating)
|
Dimensions (W x D x H) |
- 83 x 110 x 155 mm (3.27" x 4.33" x 6.10")
|
Weight (net/gross) |
- Full: 1.75 kg (3.86 lb)
- Simplified: 1.65 kg (3.84 lb)
|
Certifications |
- CE (Class A), FCC (Class A)
|
EOS Support |
|
Software Support |
|
Mounting |
|
