CPU |
- LGA1700 socket 12th gen Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor, up to 125W
|
Chipset |
|
Graphics |
|
System Memory |
- 4 x 288-pin DDR4-3200 R-DIMM unbuffered non-ECC memory, up to 128GB
|
BIOS |
|
Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
Cooling |
|
Drive Capacity |
- Exposed: 3 x 5.25" HDD drive bay
- Internal: 1 x 3.5" & 1 x 2.5" HDD drive bay
|
Expansion |
- Slot1: PCIe x16 (Gen4)
- Slot2: PCIe x4 (Gen4)
- Slot3: PCIe x4 (Gen4)
- Slot5: PCIe x4 (Gen4)
- Slot6: PCI
- Slot7: PCIe x4 (Gen4)
- 1 x M.2 Key B 2230 (PCIe & USB 2.0 signal)
|
Storage |
- 4 x SATA3 with RAID 0/1/5/10
- 1 x NVMe M.2 Key M 2280 (PCIe x4)
|
Ethernet |
- 1 x 10/100/1000/2500 Mbps with Intel® I225-V
- 1 x 10/100/1000 Mbps with Intel® I219-V
|
COM |
- 1 x RS-232 (rear I/O)
- 3 x RS-232 (internal box header)
- 1 x RS-232/422/485 (internal box header)
- 1 x RS-232/485 (internal box header)
|
USB |
- 4 x USB 3.2 Gen1x1 (5Gbps, rear I/O)
- 2 x USB 2.0 (rear I/O)
- 4 x USB 2.0 (internal pin header)
- 1 x USB 2.0 (internal 180D type A)
|
Audio |
- HD Codec audio as MIC-in/Line-in/Line-out
|
Digital I/O |
|
PS/2 |
|
Display |
- 1 x VGA, up to 1920x1200 @60Hz
- 1 x HDMI 1.4b, up to 4096x2160 @24Hz
- 1 x DVI-D, up to 1920×1200 @60Hz
|
SMBus |
|
Power Supply |
- 750W
- AC input voltage: 100 to 240V
|
Operating Temperature |
- 0°C to +40°C (+32°F to +104°F)
|
Relative Humidity |
- 10% - 95%, non-condensing
|
Dimensions (W x D x H) |
- 462 mm (18.2") (W) x 330 mm (13") (H) x 196 mm (7.7") (D)
|
Weight (net/gross) |
|
Certifications |
|
OS Support |
|
