| CPU |
- Intel Atom® x6413E (1.5GHz)
- Intel Atom® x6414RE (1.5GHz)
- Intel® Celeron® N6210 (1.2GHz)
- Intel® Celeron® J6412 (2.0GHz)
|
| Chipset |
|
| System Memory |
- 8GB/16GB LPDDR4 memory onboard, up to 3200MT/s
|
| BIOS |
|
| Serial |
|
| USB |
- 2 x USB 3.2 Gen2
- 8 x USB 2.0
|
| Ethernet |
- 1 x 10/100/1000/2500 Mbps Ethernet (Intel® I226LM)
|
| Display |
- 1 x DDI
- 1 x LVDS (eDP optional)
|
| GPIO |
|
| Audio |
- HD link interface to baseboard for Codec
|
| Storage |
- 32GB/64GB eMMC onboard
- 2 x SATA 3.0
|
| Expansion |
|
| Others |
|
| Battery |
|
| Power Input |
- ATX: +12V, +5VSB
- AT: +12V
- Wide range input: +4.75V to +20V
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- Industrial: -40°C to +85°C (-40°F to +185°F) with system thermal solution
- Standard: -20°C to +70°C (-4°F to +158°F)
|
| Relative Humidity |
- 10% - 95% relative humidity, non-condensing
|
| Vibration |
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
