| CPU |
- LGA1700 socket 14th/13th/12th gen Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor (up to 65W)
|
| Chipset |
|
| System Memory |
- 4 x DDR4-3200 Long-DIMM, up to 128GB
|
| BIOS |
|
| COM |
- 2 x RS-232/422/485
- 4 x RS-232
|
| USB |
- 10 x USB 3.2 Gen1
- 2 x USB 2.0 with 2x5-pin wafer
|
| Ethernet |
- 2 x 10/100/1000/2500 Mbps (Intel® I226-LM)
- 2 x 10/100/1000/10000 Mbps (Intel® X550-AT2; optional)
|
| Display |
- 1 x DisplayPort++
- 1 x VGA
- 2 x HDMI
|
| Digital I/O |
- 8-channel in/out programmable
|
| Audio |
|
| Storage |
- 6 x SATA 3.0 with RAID 0/1/5/10
- 1 x M.2 Key M 2280 with NVMe support
|
| Expansion |
- 1 x PCIe x16
- 2 x PCIe x4
- 1 x PCIe x1
|
| Others |
|
| Battery |
|
| Power Requirements |
- 24+8-pin ATX connector with AT Mode Auto Power support
|
| Watchdog Timer |
- 255 levels, 1 to 255 sec.
|
| Hardware Monitoring |
|
| Operating Temperature |
- 0°C to +60°C (+32°F to +140°F)
|
| Relative Humidity |
- 10% to 95% relative humidity, non-condensing
|
| Dimensions |
|
| Board Thickness |
|
| Certifications |
|
