| LCD Panel |
- 21.5" FHD TFT LCD
- 400 nits
- 1920 x 1080 pixels
|
| CPU |
- Intel® Core™ i5-1335UE 1.3 GHz or processor U300E 1.1 GHz
|
| Chipset |
|
| System Memory |
- 1 x 262-pin DDR5 SO-DIMM, up to 48GB
|
| BIOS |
|
| COM |
- 1 x RS-232/422/485 (default RS-232, A-coded)
|
| USB |
- 1 x USB 2.0 dual-port (A-coded)
|
| Ethernet |
- 1 x 2.5GBase-T Ethernet with Intel® I226 (X-coded)
- 1 x 1GBase-T Ethernet with Intel® I210 (X-coded)
|
| Display |
|
| Audio |
|
| Storage |
- 1 x M.2 2280, NVMe (Gen4x4) or auto-detect SATA
- 1 x mSATA
|
| Expansion |
- 1 x Full-size PCIe Mini Card slot (USB + PCIe/SATA) with nano-SIM socket; supports PCIe Mini Card or mSATA with auto-detection
- 1 x M.2 Key E 2230 slot for Wi-Fi + Bluetooth module
- 1 x M.2 Key M 2280 slot (PCIe Gen4 x
|
| Others |
|
| Touchscreen |
- Projected capacitive multi-touch
|
| Enclosure |
- Stainless steel (SUS) 304 or 316 (optional)
|
| Power Supply |
|
| Power Comsumption |
|
| Watchdog Timer |
- 65536 levels, 0 to 65535 sec.
|
| Operating Temperature |
- 20°C to +50°C (-4°F to +122°F)
|
| Relative Humidity |
- 10% to 95% @ +40°C, non-condensing
|
| Vibration |
- 1G, 5 to 500Hz, random for M.2 SSD
|
| Dimensions (W x D x H) |
- 531.6 x 60.5 x 318 mm (20.93" x 2.38" x 12.52")
|
| Weight (net/gross) |
- 7.5 kg (16.53 lb)/11 kg (24.25 lb)
|
| Certifications |
- CE Class A, IEC/EN 61000-6-4, IEC/EN 61000-6-2
- FCC 47 CFR Part 15 Subpart B (Class A)
- UKCA
- RoHS standard
|
| EOS |
- Windows® 10, Windows® 11 and Linux
|
| Mounting |
|
